Description
- 38.5 cc petrol engine with a power output of 1.6 kW
- 35 cm (14″) cutting bar
- Chain speed of 22.8 m/s
- Net weight of 5.64 kg without bar and chain
- 5-year warranty (T&C’s Apply)
- Tensioning wrench supplied
GENERAL INFO
Series Series 5
SKU 240381402/ST1
Level Experience
EAN/UPC 8008984853461
POWER
Power 1.6 kW
Power source Petrol 2-stroke
Displacement 38.5 cm³
Engine rotation speed 12000 rpm
Maximum engine speed 12000 rpm
Idling speed (+/- 100) 3100 rpm
Starter Recoil
Primer Yes
Choke Manual with automatic return
Fuel tank capacity 0.51 l
Carburettor type Butterfly valve
Ignition coil type Digital
Air filter type Nylon net
CUTTING SYSTEM
Bar type Sprocket nose
Bar length 35 cm
Bar length (inches) 14 in
Chain type 3/8″ .050″ (91PX-53X)
Chain speed 22.8 m/s
Chain brake Manual and inertial
Chain oil tank capacity 0.26 l
Chain oil pump Automatic adjustable
Chain tensioning system Side screw tensioning
EQUIPMENT
Handle type Rear handle
Vibe Control System (VCS) Yes
Soft grip handle Yes
TOOLS KIT
Included tools kit Screwdriver, chain round file, spark plug key
VIBRATION AND NOISE DATA Vibration level front handle (m/s2) 5.72
Vibration level rear handle (m/s2) 4.37
Guaranteed sound power level (LwA) – dB(A) 115
Measured sound pressure level at operator ear dB(A) 99.6
Measured sound power level dB(A) 111.5
OVERALL DIMENSIONS
Pack weight 7.94 kg
Weight 7.295 kg
Product weight without bar and chain 5.64 kg
Product length 724 mm
Product width 283 mm
Product height 315 mm
